PID Controller: SRS3-I-N16-002
Specification:
Size: 96 x 96
Input: Voltage input (0–10 V) (with shunt resistor for 4-20mA input)
Output: Current: 4–20 mA DC Load resistance: 600 Ω max. (OPTION)
- 6 To 10 Qty at Rs.3900
- 11 To 15 Qty at Rs.3800
Product Feature:
1. Multi-input and multi-range performance.
2. Small instrument depths (62 mm–65 mm) save space, thus securing a larger installation area.
3. Large 13.8 mm bright display (SRS1 & SRS4), 21.8 mm (SRS3) & 22mm (SRS5).
4. 1 Pattern, 10 step program function available (option).
|
Item |
Code |
Specification |
|
Series
|
SRS1- |
48*48 DIN Size Digital Controller |
|
SRS3- |
96*96 DIN Size Digital Controller |
|
|
SRS4- |
96*48 DIN Size Digital Controller |
|
|
SRS5- |
48*96 DIN Size Digital Controller |
|
|
Control Output |
Y |
Contact: 1a, Contact capacity: 240 V AC 2A/resistive load Proportional cycle: 1–120 sec. |
|
P |
SSR drive voltage: 12 V±1.5 V DC/20mA max. Proportional cycle: 1–120 sec. |
|
|
I |
Current: 4–20 mA DC Load resistance: 600 Ω max. (OPTION) |
|
|
V |
Voltage: 0–10 V DC Load current: 2 mA max. |
|
|
Program Function |
N |
None |
|
P |
1 Pattern 10 Steps |
|
|
Event Output |
1 |
2 Point 240V AC 1.0A Common |
|
Remark |
0 |
Without |
|
6 |
Voltage input (V) |
|
|
9 |
With (Please consult before ordering.) |
